Semi-Fowler Manual Hospital Bed with ABS - ATD SF1-2026
Single crank backrest raise • Pressed steel base • Removable ABS boards
KEY FEATURES
Single-Crank Backrest Elevation
Smooth manual crank-operated backrest raise allows easy positioning for patient eating and breathing.
Torque-Release Foldable Crank
Retractable crank handle with torque-release mechanism prevents mechanical strain and folds under the frame.
Pressed Steel Mattress Base
Solid pressed steel mattress platform treated with corrosion-resistant epoxy powder coating.
Removable ABS Head & Foot Boards
Impact-resistant ABS plastic boards with auto-locking stoppers for rapid removal, cleaning, and airway access.
Collapsible Aluminium Side Rails
Aluminium alloy side safety rails fold down easily with one-touch latching to facilitate patient transfer.
125 mm Single-Locking Castors
Smooth-rolling 125 mm diameter wheel castors equipped with individual foot brakes.
Anti-Collision Corner Bumpers
Resilient buffer rollers located at all four corners protect hospital walls and bed frame during transit.
Ward Utility Provisions
Pre-installed urine bag holder hooks and multiple IV drip rod socket locations.
Optional High-Density Mattress
Compatible with high-density elastic sponge waterproof mattress (Size: L 770+1200 mm, W 890 mm).
TECHNICAL PARAMETERS
DETAILED TECHNICAL SPECIFICATIONS
| Overall Dimensions | L2100 x W980 x H500 mm |
| Bed Height | Fixed at 500 mm |
| Backrest Range | 0 - 75° (Manual Crank) |
| Mattress Platform | Pressed steel base with epoxy powder coating |
| Crank Mechanism | Single crank with torque-release fold-away handle |
| Head & Foot Boards | Removable ABS plastic with auto-locking stopper |
| Side Rails | Collapsible aluminium alloy safety rails |
| Castors | 125 mm single-locking wheel casters |
| Corner Protection | Anti-bumper rollers in four corners |
| Safe Load Capacity | ≥ 200 kg |
| Included Accessories | Urine bag holder, IV rod locations |
Precision Clinical Advantages
Single-Crank Backrest Elevation
Smooth manual crank-operated backrest raise allows easy positioning for patient eating and breathing.
Torque-Release Foldable Crank
Retractable crank handle with torque-release mechanism prevents mechanical strain and folds under the frame.
Pressed Steel Mattress Base
Solid pressed steel mattress platform treated with corrosion-resistant epoxy powder coating.
Removable ABS Head & Foot Boards
Impact-resistant ABS plastic boards with auto-locking stoppers for rapid removal, cleaning, and airway access.
Collapsible Aluminium Side Rails
Aluminium alloy side safety rails fold down easily with one-touch latching to facilitate patient transfer.
125 mm Single-Locking Castors
Smooth-rolling 125 mm diameter wheel castors equipped with individual foot brakes.
Anti-Collision Corner Bumpers
Resilient buffer rollers located at all four corners protect hospital walls and bed frame during transit.
Ward Utility Provisions
Pre-installed urine bag holder hooks and multiple IV drip rod socket locations.
Optional High-Density Mattress
Compatible with high-density elastic sponge waterproof mattress (Size: L 770+1200 mm, W 890 mm).
Where This Product Is Used
ICU & Critical Care
Optimal for high dependency patient care and continuous monitoring.
Emergency Response
Designed for rapid mobility, central locking, and instant release.
General Patient Wards
Comfortable ergonomic positioning for patient recovery and nursing ease.
